Guest Post by Willis Eschenbach [See update at the end]
I started out as a true believer that sunspots (or something that changes in sync with sunspots, like heliomagnetism, cosmic rays, solar wind, etc.) had a strong effect on the weather. When I was a kid I read that the great British astronomer William Hershel had said that British wheat prices were affected by the sunspot cycle. Made sense to me …
So when I started looking into the question, I figured it would be a piece of cake to find evidence supporting the connection … but nothing in climate science is simple. I started by looking into Hershel’s claim, and I was going to write it up … but then I found a scientific paper entitled “On the insignificance of Herschel’s sunspot correlation“. I hadn’t put much time into my research, and it was much better than my poor attempt. It clearly showed that Herschel was … well … not to put too fine a point on it, completely wrong.
Undaunted, I continued to look for correlations, and I’ve done so from time to time ever since. At this point I’ve looked in more than 20 places, and found no correlation. I append these studies at the end of this post.
Yesterday, a chance comment about sea surface temperature (SST) gave me a new thought about how to look for the signal. In general, I’ve looked at various time-series records of some parameter—river levels, lake levels, cloud amounts, volcanoes, and the like. I’ve analyzed them either with Fourier Analysis or CEEMD analysis.
Anyhow, the idea I had was to divide monthly gridded temperature datasets into months where the sunspots were higher than the median sunspot number for the period, and months where sunspots were lower than that median. Then, I’d subtract the gridcell-by-gridcell average of the low-sunspot months from that of the high-sunspot months. If the theory that low sunspot cycles were associated with low temperatures were true, I’d expect to find a positive difference between the two.
Since the original idea was about sea surface temperature (SST), I thought I’d start with that. The best gridded SST dataset I know of is the Reynolds OI dataset. It starts in 1981, and uses a mixture of satellite and surface data. From the NOAA site:
The NOAA 1/4° daily Optimum Interpolation Sea Surface Temperature (or daily OISST) is an analysis constructed by combining observations from different platforms (satellites, ships, buoys) on a regular global grid. A spatially complete SST map is produced by interpolating to fill in gaps.
It’s available here as a NetCDF document. Figure 1 shows the result of the analysis.
Figure 1. Average of high-sunspot-number months minus the average of low-sunspot-number months, Reynolds Optimally Interpolated Sea Surface Temperature. “High-sunspot” months averaged 135 sunspots; “low-sunspot” months averaged 26 sunspots.
As you can see, not only is the difference very tiny, it has the wrong sign. If low sunspot numbers actually lead to low temperatures, then high minus low should give a positive result. But in this case, it’s a negative result, and it’s only four-hundredths of one degree. In other words … no sign of sunspots affecting the SST.
Next, I thought I’d take a look at a global dataset. I used the Berkeley Earth gridded land and ocean data. I picked an arbitrary cutoff date of 1950, because observations before that start getting sparse. The data is available here as a NetCDF document. I did the same thing, dividing it into high-sunspot and low-sunspot months, and subtracted the low from the high. Figure 2 shows the results.
Figure 2. As in Figure 1, but with the Berkeley Earth global temperature data. Over this period, “High-sunspot” months averaged 155 sunspots; “low-sunspot” months averaged 33 sunspots.
Once again … same result. Wrong sign, tiny difference, no apparent effect of sunspots on the global temperature.
This finding is supported by a CEEMD analysis of the datasets. Here are the results for the Reynolds data:
You can see the sunspot peak (red line, Empirical Mode 6) at about 11.5 years. There’s nothing to match it in the Reynolds OI SST data. And here’s the corresponding chart for the Berkeley Earth data:
In this longer dataset, the sunspot period is 11 years, closer to the long-term average. And as with the Reynolds data, there is no 11-year cycle in the temperature records.
Conclusion? Once again, I’ve looked for a solar signal and found none.
Does this mean that the sunspot cycle doesn’t affect surface weather?
Nope. It just means that I haven’t been able to find one. Might be out there, but I’m up to 25 places or so that I’ve looked without finding it.
[UPDATE] In the comments, someone pointed to a study claiming that the winters in Eurasia are colder when sunspots are low. So I got the Berkeley Earth data and looked at the winter [DJF]. I used data back to 1900, although it’s less accurate, because I needed the longer period to have enough data to study just the wintertime. Once again … no joy.
Figure 3. Winter (DJF) high and low sunspot months. Over this period, “High-sunspot” months averaged 144 sunspots; “low-sunspot” months averaged 28 sunspots.
Update 2. I did the same analysis using the UAH MSU satellite-based lower troposphere temperatures.
Figure 4. As in Figure 1, but with the UAH MSU satellite lower troposphere temperature data.
12:32 AM here, my eyelids are drooping. Hang on, let me go outside … ah, great lungfuls of crisp air on a starry moonless night have me back in shape. Can’t hear the ocean, the wind is wrong. It’s 38°F, or 3°C, the forest is quiet, life is good. I’ll leave this here and come back to trim it up for publication in the morning.
11:30 AM, next morning. Sun is out, the tiny bit of the ocean I can see from our house is shining in the sunshine …
Ah, dear friends, what a world this is!
Best to all,
w.
PS: When you comment please quote the exact words you’re discussing, so we can all understand your subject.
FURTHER READING: Here are my previous posts on the subject.
Congenital Cyclomania Redux 2013-07-23
Well, I wasn’t going to mention this paper, but it seems to be getting some play in the blogosphere. Our friend Nicola Scafetta is back again, this time with a paper called “Solar and planetary oscillation control on climate change: hind-cast, forecast and a comparison with the CMIP5 GCMs”. He’s…
Cycles Without The Mania 2013-07-29
Are there cycles in the sun and its associated electromagnetic phenomena? Assuredly. What are the lengths of the cycles? Well, there’s the question. In the process of writing my recent post about cyclomania, I came across a very interesting paper entitled “Correlation Between the Sunspot Number, the Total Solar Irradiance,…
Sunspots and Sea Level 2014-01-21
I came across a curious graph and claim today in a peer-reviewed scientific paper. Here’s the graph relating sunspots and the change in sea level: And here is the claim about the graph: Sea level change and solar activity A stronger effect related to solar cycles is seen in Fig.…
Riding A Mathemagical Solarcycle 2014-01-22
Among the papers in the Copernicus Special Issue of Pattern Recognition in Physics we find a paper from R. J. Salvador in which he says he has developed A mathematical model of the sunspot cycle for the past 1000 yr. Setting aside the difficulties of verification of sunspot numbers for…
Sunny Spots Along the Parana River 2014-01-25
In a comment on a recent post, I was pointed to a study making the following surprising claim: Here, we analyze the stream flow of one of the largest rivers in the world, the Parana ́ in southeastern South America. For the last century, we find a strong correlation with…
Usoskin Et Al. Discover A New Class of Sunspots 2014-02-22
There’s a new post up by Usoskin et al. entitled “Evidence for distinct modes of solar activity”. To their credit, they’ve archived their data, it’s available here. Figure 1 shows their reconstructed decadal averages of sunspot numbers for the last three thousand years, from their paper: Figure 1. The results…
Solar Periodicity 2014-04-10
I was pointed to a 2010 post by Dr. Roy Spencer over at his always interesting blog. In it, he says that he can show a relationship between total solar irradiance (TSI) and the HadCRUT3 global surface temperature anomalies. TSI is the strength of the sun’s energy at a specified distance…
Cosmic Rays, Sunspots, and Beryllium 2014-04-13
In investigations of the past history of cosmic rays, the deposition rates (flux rates) of the beryllium isotope 10Be are often used as a proxy for the amount of cosmic rays. This is because 10Be is produced, inter alia, by cosmic rays in the atmosphere. Being a congenitally inquisitive type…
The Tip of the Gleissberg 2014-05-17
A look at Gleissberg’s famous solar cycle reveals that it is constructed from some dubious signal analysis methods. This purported 80-year “Gleissberg cycle” in the sunspot numbers has excited much interest since Gleissberg’s original work. However, the claimed length of the cycle has varied widely.
The Effect of Gleissberg’s “Secular Smoothing” 2014-05-19
ABSTRACT: Slow Fourier Transform (SFT) periodograms reveal the strength of the cycles in the full sunspot dataset (n=314), in the sunspot cycle maxima data alone (n=28), and the sunspot cycle maxima after they have been “secularly smoothed” using the method of Gleissberg (n = 24). In all three datasets, there…
It’s The Evidence, Stupid! 2014-05-24
I hear a lot of folks give the following explanation for the vagaries of the climate, viz: It’s the sun, stupid. And in fact, when I first started looking at the climate I thought the very same thing. How could it not be the sun, I reasoned, since obviously that’s…
Sunspots and Sea Surface Temperature 2014-06-06
I thought I was done with sunspots … but as the well-known climate scientist Michael Corleone once remarked, “Just when I thought I was out … they pull me back in”. In this case Marcel Crok, the well-known Dutch climate writer, asked me if I’d seen the paper from Nir…
Maunder and Dalton Sunspot Minima 2014-06-23
In a recent interchange over at Joanne Nova’s always interesting blog, I’d said that the slow changes in the sun have little effect on temperature. Someone asked me, well, what about the cold temperatures during the Maunder and Dalton sunspot minima? And I thought … hey, what about them? I…
Changes in Total Solar Irradiance 2014-10-25
Total solar irradiance, also called “TSI”, is the total amount of energy coming from the sun at all frequencies. It is measured in watts per square metre (W/m2). Lots of folks claim that the small ~ 11-year variations in TSI are amplified by some unspecified mechanism, and thus these small changes in TSI make an…
Splicing Clouds 2014-11-01
So once again, I have donned my Don Quijote armor and continued my quest for a ~11-year sunspot-related solar signal in some surface weather dataset. My plan for the quest has been simple. It is based on the fact that all of the phenomena commonly credited with affecting the temperature,…
Volcanoes and Sunspots 2015-02-09
I keep reading how sunspots are supposed to affect volcanoes. In the comments to my last post, Tides, Earthquakes, and Volcanoes, someone approvingly quoted a volcano researcher who had looked at eleven eruptions of a particular type and stated: …. Nine of the 11 events occurred during the solar inactive phase…
Early Sunspots and Volcanoes 2015-02-10
Well, as often happens I started out in one direction and then I got sidetractored … I wanted to respond to Michele Casati’s claim in the comments of my last post. His claim was that if we include the Maunder Minimum in the 1600’s, it’s clear that volcanoes with a…
Sunspots and Norwegian Child Mortality 2015-03-07
In January there was a study published by The Royal Society entitled “Solar activity at birth predicted infant survival and women’s fertility in historical Norway”, available here. It claimed that in Norway in the 1700s and 1800s the solar activity at birth affected a child’s survival chances. As you might imagine, this…
The New Sunspot Data And Satellite Sea Levels 2015-08-13
[UPDATE:”Upon reading Dr. Shaviv’s reply to this post, I have withdrawn any mention of “deceptive” from this post. This term was over the top, as it ascribed motive to the authors. I have replaced the term with “misleading”. This is more accurate…
My Thanks Apologies And Reply To Dr Nir Shaviv 2015-08-17
Dr. Nir Shaviv has kindly replied in the comments to my previous post. There, he says: Nir Shaviv” August 15, 2015 at 2:51 pm There is very little truth about any of the points raised by Eschenbach in this article. In particular, his analysis excludes the fact that the o…
Is The Signal Detectable 2015-08-19
[UPDATE] In the comments, Nick Stokes pointed out that although I thought that Dr. Shaviv’s harmonic solar component was a 12.6 year sine wave with a standard deviation of 1.7 centimetres, it is actually a 12.6 year sine wave with a standard deviation of 1.7 millime…
The Missing 11 Year Signal 2015-08-19
Dr. Nir Shaviv and others strongly believe that there is an ~ 11-year solar signal visible in the sea level height data. I don’t think such a signal is visible. So I decided to look for it another way, one I’d not seen used before. One of the more sensitive …
23 New Papers 2015-09-22
Over at Pierre Gosselin’s site, NoTricksZone, he’s trumpeting the fact that there are a bunch of new papers showing a solar effect on the climate. The headline is Already 23 Papers Supporting Sun As Major Climate Factor In 2015 “Burgeoning Evidence No Longer Dismissible!…
The Cosmic Problem With Rays 2016-10-17
Normal carbon has six neutrons and six protons, for an atomic weight of twelve. However, there is a slightly different form of carbon which has two extra neutrons. That form of carbon, called carbon-14 or ’14C’, has an atomic weight of fourteen. It is known to be formed by the …
