A Deterministic Forecast of Future Climate Changes

By Renee Hannon


In my previous WUWT post, I proposed a conceptual process model describing the influences of astronomical controls on interglacial warm periods and glacial cycles (Figure 1). The warm onsets with rapidly increasing temperatures are triggered by an increase in the eccentricity of Earth’s orbit, an increase in obliquity and an increase in summer insolation. The nearly concurrent increase in these astronomical forces is a necessary component for a significant interglacial warm onset. Obliquity is the dominant control on duration and cooling of these major warm periods (Javier). Summer insolation which retains the higher frequency signal of precession may modify warm duration patterns or influence stadial and interstadial occurrences.

Figure 1: Conceptual process model of Milankovitch cycles influence on interglacial warm period temperature variations. Horizontal axis is relative time for kyr. Warm onset occurs during increasing Eccentricity, Obliquity, and NH summer insolation. Obliquity is the dominant control over cooling and thus, warm duration.

In this post, I attempt to address the conundrum “It is not a question if cooling will occur but simply a question of when”. By using a deterministic approach based on the astronomical process model and paleoclimate analogs, approximations are developed for future significant climate events. These events include the end of our current Holocene warm period, length of the current glacial cycle and onset of the next warm interglacial period. This deterministic forecast is not intended as a prediction of the future. Rather, it is an attempt to investigate a set of discrete assumptions using astronomical forces as the key trigger for major climate temperature events.

A deterministic model helps tune primary controls and evaluate a range of outcomes for a climate forecast. This skeleton climate framework displays large scale global temperature patterns that may enable others to infill additional primary and secondary higher frequency temperature events.


Antarctica Dome C ice core deuterium isotope ratios converted to temperatures are used as the central dataset for this study. These data were chosen because less temperature sensitivity to northern hemisphere events are evident. This allows for identification of global temperature events versus higher frequency temperature variations such as the North Atlantic Ocean oscillations as seen in the Greenland ice core data.

Calculated temperatures from the Antarctica Dome C data are multiplied by 0.5 to approximate global temperatures rather than polar temperature regions. Uncorrected, the magnitude of the delta degree C would be double than what is stated throughout in this post.

Past and future orbital parameters of the Milankovitch Cycles for eccentricity changes in Earth’s orbit, obliquity or tilt of Earth’s axis, and precession which affects seasonal distribution of radiation are from J. Laskar (2004). Insolation or solar radiation calculations from these orbital parameters for various latitudes and seasons are also from Laskar (2004). Northern Hemisphere summer insolation at 65 degrees which is strongly influenced by precession is used in this post.

Past Glacial Cycles Overview

Glacial cycles over the past 450 kyrs are demonstrated to vary in duration from 89 to 119 kyrs and consist of a warm interglacial period, a mild glacial period and a full glacial period as shown in Figure 2. This variation in past glacial cycle durations correlates to eccentricity and northern hemisphere summer insolation cycles (see Hannon Figure 8).

Figure 2: A traverse of the past five interglacial-glacial cycles is datumed (the datum for the curves is the red line at the bottom of the traverse) on the Warm Onsets. EPICA Dome C isotope temperature estimates are plotted as curves in 1 degree C increments on the horizontal scale (cold to left and warm to right). The vertical scale is time in 20 kyr increments. Actual age is plotted on each cycle. Interglacial warm periods are highlighted in red and the coldest portion of the glacial period in blue. Dark red is used above Δ-1°C, this cutoff is also used to calculate the warm period duration.

The key glacial cycle event is the termination of the full glacial period and the onset of the warm interglacial period. This event bounds each glacial cycle as shown in Figure 2. This has happened five times over the past 450 kyrs. These warm periods exhibit an onset of rapid warming with significant global temperature increases of 5 to 7+ degrees C in just 5 to 7 kyrs. The cooling of warm periods is more gradual with temperatures dropping by 3 to 4 degrees C over 8 to 14 kyrs. The Holocene present day is currently within a warm interglacial period as it has been for the past 12 kyrs.

Several smaller warm events (interstadials) and abridged cooling events (stadials) which last only thousands of years occur within each warm period and mild glacial period. Many of the Holocene intermediate events include the Boiling/Allerod warming interstadial followed by the Younger Dryas Cooling Stadial, and the intervening 8.2 kyr Stadial cooling during Holocene optimum. The phasing of obliquity and higher frequency summer insolation influences the warm duration patterns and interstadials/stadials during the mild glacial periods.

Forecast Assumptions

A deterministic model is constructed for the current glacial cycle using astronomical data as a control and paleoclimate analogs over the past 450 kyrs (Figure 3). Astronomical cycles are reasonably well synchronized during the next 100 kyrs; meaning several insolation and obliquity highs and lows are close in timing. The deterministic model developed for the current Holocene interglacial duration and future cooling as well as the next interglacial warm onset uses these primary assumptions:

  • Astronomical curves are shifted by 6.5 kyrs as determined by Javier. This shift advances the curves in time and improves correlation to Earth’s past temperature changes. Astronomical forces initiate dramatic temperature changes that are buffered by Earth’s expansive oceans causing a delayed reaction to temperature shifts. Additionally, deep oceans are becoming colder and more energy is necessary to exit a glacial state as recently discussed by Röst. The delay of global temperature changes due to solar impacts warrants additional investigation. Shifting the astronomical curves is probably the largest uncertainty in the development of this deterministic forecast.
  • Temperature variations due to oceanic, atmospheric and geologic events have not been specifically incorporated. These include ocean oscillations, greenhouse gases, meteor impacts and volcanoes. These factors should be captured within bounds of the deterministic cases presented here. Their omission is a secondary uncertainty within this deterministic forecast.
  • The previous four interglacial warm periods provide temperature analog data, boundary conditions for warm period durations, as well as calculated slopes for warming and cooling trends.


Figure 3: Projected Holocene warm duration, cooling descent and subsequent interglacial onset curves plotted with Milankovitch cycles. Dome C temperature curves are in red with scale on left hand side. Astronomical cycles in blue with various scales on right hand side. The bottom horizontal axis is time in kyrs and the top horizontal axis in blue contains the M cycle values.  Calculated cooling and onset curves based on past Warm periods slopes in dashed lines with best estimate in red solid line.

Present-Day Warm Duration Forecast

Three discrete cases are constructed for the duration and eventual cooling of the Holocene interglacial warm period. Deterministic estimates are built for a minimum (P10), maximum (P90) and best estimate cases. The P10 case expects that less than 10% of the time a case could occur where cooling will be sooner. The P90 case expects that less than 10% of the time cooling will begin later. The best estimate case usually falls near the mean of the distribution.

Cooling slopes calculated for the past warm periods are shown in Table 1. Warm IV cooling slope is used for the minimum case and Warm V cooling slope for the maximum case as they are endmembers for the four past cooling slopes. Warm IV’s duration of 14 kyrs is used for the Holocene minimum warm duration case suggesting cooling will begin within a few hundred years. The minimum case cooling descent is bounded by summer insolation which is rapidly decreasing (Figure 3). Obliquity is also decreasing but has not decreased below 23.5 degrees tilt.

Table 1a: Interglacial durations (greater than minus 1 degree C) and cooling slope calculations (Hannon).

Interglacial Period

Warm Duration (kyr)

Cooling Slope

Warm I (Holocene)


see Table 1b

Warm II (MIS 5)



Warm III (MIS 7e)



Warm IV (MIS 9)



Warm V (MIS 11)



Table 1b: Deterministic cases for projected Holocene Interglacial duration and cooling slopes. Duration is defined as greater than minus 1 degree C.

Holocene Warm I

Warm Duration (kyr)

Cooling Slope

Minimum Case



Best Estimate



Maximum Case



The best estimate case for the Holocene warm period uses a duration that fits obliquity when tilt begins decreasing below 23.5 degrees (Figure 3). The Holocene warm duration, in the best estimate case, is interpreted to be 19-20 kyrs long and will begin a cooling descent about 4 kyrs from present day. The cooling descent is expected to last approximately 10 kyrs as observed in past warm endings which would result in reduced global temperatures of 3-4 degrees C.

The maximum case for the Holocene warm duration is 27 kyrs with a cooling descent about 8+ kyrs from present day. This case roughly corresponds to decreasing eccentricity. Obliquity and insolation have already decreased. The maximum case is expected to be shorter in duration than Warm V. Warm V has a pronounced insolation increase during the middle of its warm duration which extended the warm period. A strong insolation increase is not present during the later portion of the Holocene warm period and therefore, Warm V’s extended warm duration was not used as a reasonable maximum case. However, it would not be surprising to see an increase in average global temperature of 1-2 degrees C during the remaining Holocene warm period. This is because our current interglacial warm period has been cooler than the warm optimum of past warm periods by 1-2 degrees C (Hannon).

Glacial Cycle I and Future Warm Onset Forecast

Significant warm onsets occur when eccentricity, obliquity, and summer insolation are concurrently increasing. Therefore, the potential onset of the next warm interglacial period was positioned at approximately 62 kyrs (+/- 3 kyrs) from present day (Figure 3). This assumes one obliquity cycle is skipped because eccentricity is decreasing and near circular during this time. Note the future warm onset has both obliquity and insolation increasing simultaneously.

The slope of the future Warm onset at 62 kyrs was constructed in a similar fashion as the cooling slopes and utilizes observations from warming slopes during the past 450 kyrs (Table 2). Only two discreet cases are developed for this warm onset slope; Warm II slope is the minimum case and Warm V slope is the maximum case. Since obliquity and insolation are increasing at the same time, this may result in an onset more like Warm II rather than Warm V. The steep slope of Warm III was not used because it was initiated during a predominately elliptical eccentric cycle where obliquity and insolation are amplified.

Table 2: Warm Onset Slopes for the past 450 kyrs and cases used in deterministic onset slope calculations.

Warm Period

Warm Onset Slope

Future Warm Onset Slope

Warm II (MIS 5)


0.89 min Case

Warm III (MIS 7e)


Warm IV (MIS 9)


Warm V (MIS 11)


0.68 max Case

If the future interglacial warm onset occurs in 62 kyrs and the onset of the current Holocene Warm period was 17 kyrs ago, then the duration of Glacial Cycle I will be approximately 79 to 80 kyrs. This will make the current glacial cycle the shortest glacial cycle in the past 450 kyrs (Figure 2). This is plausible because current eccentricity cycle is predominantly circular and shorter in duration than the past three eccentricity cycles.

As demonstrated in my previous post, eccentricity and summer insolation cycle length correlate reasonably well with the duration of glacial cycles. Glacial Cycle V occurs when eccentricity cycles are predominately circular. Glacial Cycle V is a short glacial cycle and lasted only 89 kyrs shown in Figure 2. Because Earth is currently in a predominantly circular orbit, Glacial Cycle I is more likely to be analogous to Glacial Cycle V with a potentially shorter glacial cycle. Predominantly circular eccentricity orbits occur approximately every 400 kyrs which includes the present-day Glacial Cycle I, Glacial Cycle V (MIS 11) and MIS 19 glacial cycle as discussed by Javier.

A Conceptual Forecast

Now that the key framework onset and cooling components for the future Glacial Cycle and Holocene warm period duration have been deterministically constructed, the conceptual forecast showing various glacial periods and phases are interpreted as shown in Figure 4. For simplicity, only the best estimate for the Holocene warm duration and cooling are plotted.

Figure 4: Forecast for the Holocene warm period and Glacial Cycle I overlain on obliquity and summer insolation. Glacial periods and components are shown as colored bars in the middle of the graph and are approximations with a +/- error bar of 3 kyrs.

The mild glacial period and glacial maximum are estimated for the current Glacial Cycle I by using key astronomical forces as a guide. After the current warm duration and cooling, a mild glacial period is expected to follow. Several interstadials and stadials are interpreted to occur during the mild glacial period caused by increases and decreases in summer insolation. Around 30 kyrs from now both obliquity tilt along with summer insolation increase perhaps creating a substantial interstadial. Interstadial and stadial events can be correlated within past mild glacial periods suggesting a recurring and predictable forcing such as interplay between summer insolation and obliquity as shown in Figure 2 (yellow lines).

The next glacial maximum is placed at approximately 55 kyrs from present when both obliquity and insolation are decreasing in phase and reach their lows. Glacial maximum’s can last up to 10 kyrs in duration. As discussed, the future warm onset occurs at approximately 62 kys ending Glacial Cycle I’s glacial maximum. The warm duration and cooling for the future interglacial have not been calculated in any detail and are simply blocked in using obliquity as a guide.


A deterministic framework for forecasting the current glacial cycle is constructed using astronomical forces which are correlated to past paleoclimate isotope/temperature data. This skeletal framework, although uncomplicated in design, provides a basic forecast of future major climate changes within our current glacial cycle.

Based on the past four warm periods, the present-day Holocene warming is expected to range in duration from 14 to 27 kyrs with a best estimate of 19 kyrs. The best estimate case is also controlled by the obliquity cycle and results in a Holocene cooling descent beginning in about 4 kyrs.

As seen in past warming onsets, an increase in eccentricity, obliquity, and summer insolation are required. The next concurrent increase of these astronomical cycles is interpreted to initiate a future interglacial in approximately 62 kyrs from present day. This will terminate the current glacial cycle making it one of the shortest glacial cycles in the past 450 kyrs lasting approximately 80 kyrs. A short glacial cycle is a reasonable forecast given the current eccentricity cycle is a predominately circular orbit like Warm V (MIS 11) and MIS 19 which also have short glacial cycles.

This model is one scenario and intended more to stimulate discussion on important climate premises rather than be a definitive forecast. Key uncertainties include the 6.5 kyr shift in astronomical data and exclusion of other climate drivers. The model does illustrate how astronomical forces can be used to help explain both observed and forecasted temperature variations that significantly impact our planet.

Acknowledgements: Special thanks to Andy May and Donald Ince for reviewing and editing this article.
